SKF 2308 ETN9/C3 Self-aligning Ball Bearing
€57,96
Unit price
/
Unavailable
Description
Description
SKF 2308 ETN9/C3 - non-disassemblable double-row self-aligning ball bearing with an optimized internal design, plastic cage made of glass-fiber reinforced polyamide 6.6, guided by two rows of balls and with a radial clearance greater than normal.
The outer ring has a common spherical raceway for both rows of balls, allowing the bearing to tilt and compensate for misalignment or shaft deflection relative to the housing. The bearing can operate at temperatures up to +120°C.
Parameters
Parameters
Cage:
Plastic
Diameter D (mm):
90
Width B (mm):
33
Maximum temperature °C:
120 °C
Type:
tilting ball bearing
Clearance:
C3
Designation:
2308 ETN9/C3
