SKF 1206 ETN9/C3 Angular Contact Ball Bearing
€18,19
Unit price
/
Unavailable
Description
Description
SKF 1206 ETN9/C3 - non-disassemblable double-row angular contact ball bearing with optimized internal construction, plastic cage made of polyamide 6.6 reinforced with glass fibers, guided by two rows of balls, and with radial clearance greater than normal.
The outer ring has a common spherical raceway for both rows of balls, allowing the bearing to tilt and compensate for misalignment or shaft deflection relative to the housing. The bearing can operate at temperatures up to +120°C.
Parameters
Parameters
Cage:
Polyamide
Diameter D (mm):
30
Diameter D (mm):
62
Width B (mm):
16
Minimum temperature °C:
-30
Type:
tilting ball bearing
Designation:
1206 ETN9/C3
